Electrical System

Specs:

Voltage: 14-84V (safe for 3-20S)
Continuous Current: 50V/350A,75V/250A
Max Current: 800A
Supported sensors: ABI, HALL, AS5047, AS5048A
ERPM: 150000
Phase filter: Yes
Motor wire: 8AWG
Power cable: 8AWG
Input source: PPM, ADC, NRF, UART, PAS
Communication ports: USB, CAN, UART, SPI, IIC
CPU adaptation frequency: 168MHz (with 32F405)
Configurable RPM, current, voltage and power limits
Waterproof level (with water cooling enclosure): IP67
Size: 200*94.6*50mm (Including the height of water pipes and electrolytic capacitors)
Weight: 1.74 kg
